Overview

Our Flame Retardant High Pressure Resistant Tunnel and Mine Ventilation PVC Coated Duct is a high-performance ventilation duct solution specially designed for harsh industrial environments such as tunnels and mines. Made of high-quality PVC-coated fabric, this product integrates flame retardancy, high-pressure resistance and durability, providing a safe and reliable ventilation guarantee for underground working environments.

In tunnel and mining operations, traditional ventilation materials often fail to meet strict fire protection requirements. Our PVC-coated fabric has undergone special flame-retardant treatment, which can effectively suppress the spread of flames, reduce the risk of fire, and provide a safer working environment for workers.

The common high-pressure ventilation conditions in underground engineering can easily cause deformation or even rupture of ordinary air ducts. This product adopts a composite process of high-strength base fabric and PVC coating, featuring excellent compressive resistance. It can withstand a working pressure of up to 3500Pa without deformation.

Technical parameters

Material: High-strength polyester base fabric + special PVC coating

Thickness: 0.3mm-1mm(customizable)

Work pressure: Up to 3500Pa

Flame retardant grade: B1, B2, M1, M2, NFPA701

Operating temperature range: -40℃ to +100℃

Wind pressure resistance strength: ≥4000Pa

Tensile strength: ≥2500N/5cm in the warp direction, ≥2000N/5cm in the weft direction

Application
